PVC Rigid Pipe (Self Extinguishing)

SKU: OR1

0,00

EN61386-21-22 Approved
Material: PVC based Thermoplastic
Compression Resistance: 320 / 750 / 1250 Newton 60 Sec. 23±2°C
Impact Resistance: 1 kg. / 2 kg. -100mm.  -25°C
Temp range: -25°C +60°C.
Flame Retardant: Self-extinguishing, Cold Bendable
Main usage: Electrical Installations, Public
Buildings,Construction, Industries where high
mechanical protection is required
Colors: Any color available upon request

Attachments

Declaration of Conformity

Product Order Detail

CodeNominal SizeSize (mm.)Qty. Pack (pc.)
320N750N1250NInnerOuter
OR1-316OR2-316OR3-316161634
OR1-320OR2-320OR3-320202034
OR1-325OR2-325OR3-325252525
OR1-332OR2-332OR3-332323217
OR1-340OR2-340OR3-340404017
OR1-350OR2-350OR3-350505010
  • For other color Please add color name “OR1-316-Grey” after part code.
